Product Details
Tempat asal: Cina
Sertifikasi: ISO9001:2008
Nomor model: Selang Silikon Lurus
Payment & Shipping Terms
Kuantitas min Order: 1 meter
Harga: US$ 1/Meter
Syarat-syarat pembayaran: L/C, T/T
Warna: |
hitam, merah, biru atau disesuaikan |
Kemampuan: |
selang udara karet |
Lapisan yang Diperkuat: |
4 Lapis, Poliester/Aramid/Serat Kaca Diperkuat |
Perbaikan permukaan: |
Lempar |
Suhu Kerja: |
-40 hingga 200°c |
Bahan: |
Karet silikon |
Warna: |
hitam, merah, biru atau disesuaikan |
Kemampuan: |
selang udara karet |
Lapisan yang Diperkuat: |
4 Lapis, Poliester/Aramid/Serat Kaca Diperkuat |
Perbaikan permukaan: |
Lempar |
Suhu Kerja: |
-40 hingga 200°c |
Bahan: |
Karet silikon |
Custom High Temp 3/8 5/8 3/4 11-1/2 3 inciTabung selang pendingin air asupan karet silikon
Grafik ukuran selang silikon lurus:
| Spesifikasi - Selang silikon lurus | |||||
| KTP | OD | Ketebalan | Tekanan ledakan | Panjang | |
| Inci | mm | mm | mm | MPa | mm |
| 1/4 | 6 | 16 | 5 | 3.5 | 1000 |
| 3/8 | 10 | 20 | 5 | 2.9 | 1000 |
| 1/2 | 13 | 23 | 5 | 2.7 | 1000 |
| 5/8 | 16 | 26 | 5 | 2.4 | 1000 |
| 3/4 | 19 | 29 | 5 | 2.2 | 1000 |
| 7/8 | 22 | 32 | 5 | 2.1 | 1000 |
| 1 | 25 | 35 | 5 | 2 | 1000 |
| 1-1/2 | 38 | 48 | 5 | 1.5 | 1000 |
| 2 | 51 | 61 | 5 | 1.2 | 1000 |
| 2-1/2 | 63 | 73 | 5 | 1 | 1000 |
| 3 | 76 | 86 | 5 | 0.8 | 1000 |
| 3-1/2 | 89 | 99 | 5 | 0.6 | 1000 |
| 4 | 102 | 112 | 5 | 0.5 | 1000 |
| Produk | ID/mm | ID/inci |
| Selang silikon lurus | 6mm-102mm | 1/'-4' |
| Selang Kopling Silikon Lurus | 6mm-102mm | 1/'-4' |
| Selang Silikon Fleksibel | 13mm-63mm | 1/2'-2-1/2' |
| Selang vakum silikon | 13mm-63mm | 1/2'-2-1/2' |
| Selang pengurangan lurus silikon | 8mm-127mm | / |
| 45 derajat Reducer Silicone Hose | 25mm-102mm | / |
| 90 derajat Reducer Selang Silikon | 13mm-102mm | / |
| Selang silikon siku 45 derajat | 6mm-102mm | 1/4'-4' |
| Selang silikon siku 60 derajat | 19mm-76mm | 3/4 "-3" |
| 90 derajat siku selang silikon | 6mm-102mm | 1/4'-4' |
| 135 derajat siku silikon selang | 6mm-100mm | 1/4'-4' |
| Selang silikon siku 180 derajat | 8mm-76mm | 5/16'-3' |
| Selang Silikon Tee | 32mm-76mm | 1-1/4'-3' |
| Selang Hump Silikon | 32mm-350mm | 1-1/4'-14' |
| Selang pemanas silikon | 13mm-102mm | 1/2'-4' |
| Selang silikon kelas makanan | 3mm-31mm | 1/8'-1-1/4' |
| Selang silikon kelas medis | 6mm-102mm | 1/4'-4' |
| Selang berlapis silikon | 3mm-31mm | 1/8'-1-1/4' |
